A solar photovoltaic system (PV system) is a power system designed to supply usable solar power by means of photovoltaics; it converts sunlight or solar radiation into direct current electricity by using semiconductors. To allow users of different preparation to study this system in its variants, De Lorenzo has developed a large number of trainers that deal with it for basic, medium and high levels. For the basic level, a case has been designed containing the necessary modules to learn the first steps of this technology. For the medium level, there are different types that can satisfy both the technicians (a kit based on sub-modules) and the installers (installation kit or compact mobile structure). For the high level, also here different configurations are proposed such as solar position tracker system, off-grid and on-grid with option a light simulator in order to irradiate the solar panel in indoor places; this latter category is also supplied complete with software for data acquisition and processing. For off-grid and on-grid systems, it is also possible to replace the standard solar panel with a solar tracking panel and monitor its meaningful parameters comparing them with the expected optimal setting according to the actual sun position. Who is more interested with a simulation of solar and thermal panels with the aid of a dedicated software, he can also find here what he needs such as a simulator module. They are dedicated to schools, high schools and first years of university according to the level.

Products Details

LAMPS FOR PHOTOVOLTAIC SOLAR TRAINERS

This product is used to provide suitable lighting to the photovoltaic solar module that is used in the DL SOLAR‐B, DL SOLAR‐ D1 and DL SUN‐WIND De Lorenzo trainers.
The light intensity can be manually adjusted through a potentiometer or automatically controlled through a 0‐10 V input, to allow performing experiments with different light intensities, therefore simulating the light conditions from dawn to twilight.
The DL SIMSUN includes the following main components:
• 4 off halogen lamps, 300 W each
• Dimmer for controlling the light intensity
• Magneto‐thermal switch, differential 10 A
• Potentiometer, 10k
Approx. packing dimensions: 1.36 x 0.75 x 0.72 m.
Net weight: 20 kg.

DL SIMSUN

PHOTOVOLTAIC SOLAR ENERGY TRAINER

Didactic system for the theoretical and practical study of photovoltaic solar energy facilities.
It is mounted on a mobile structure that allows it to be moved to the venue for practical sessions and allowing the photovoltaic panel to receive solar radiation.
Complete with connecting cables and experiment manual.
TRAINING OBJECTIVES
• Identification of all components of the trainer and how they are associated with its operation
• Measurement of solar irradiation
• Measurement of the voltage and power parameters of the photovoltaic panel
• Programming the load regulator o Analysis of the installation of the trainer
• Direct current supply
• Alternating current supply
The photovoltaic panel, which can be inclined through a range of 0° to 90°, and the calibrated cell used to measure solar irradiation, are on one side, and all of the components of a basic photovoltaic facility used to provide 12 V of direct current and 230 V of alternating current are on the other side.
TECHNICAL SPECIFICATIONS
• 50 W, 12 V photovoltaic panel.
• Cell for measuring solar irradiation.
• Programmable electronic load regulator, with a large LCD screen.
• 150 Wp semi sinusoidal inverter to obtain 230 V of alternating current.
• 17 A/h battery. o Lamps used with loads of 12 V and 230 V
• Instrument used to measure solar irradiation in W/m2.
• Instrument used to measure the charging current.
• Two protective magneto-thermal switches.
AVERAGE TRAINING HOURS: 3 h
BASE DIMENSIONS: 400 x 610 mm.
HEIGHT WITH THE PANEL AT 45º: 900 mm.
Net weight: 50 kg.

DL SOLAR-A

SOLAR ENERGY MODULAR TRAINER

Modular trainer for the theoretical-practical study of the electrical installations with photovoltaic solar energy.
Complete with connecting cables, experiment manual and software for data acquisition and processing.
TRAINING OBJECTIVES
• Measurement of solar irradiation
• Measurement of the voltage of the photovoltaic panel at no-load
• Graph of current – voltage of the photovoltaic panel
• Measurement of the voltage of the panel in overload
• Regulation and charge of the battery
• Direct current solar plant
• Alternate current solar plant
• Dimensioning criteria
TECHNICAL SPECIFICATIONS
• A photovoltaic inclinable module, 90W, 12V, complete with a cell for measuring the solar irradiation and with a temperature sensor.
• A supporting frame for the modules.
• A battery.
• A battery control module, 12V, 32A.
• A load module. It includes two 12V lamps, dichroic 20W and LED 3W, with independent switches.
• A load module. It includes two mains voltage lamps, dichroic 35W and LED 3W, with independent switches.
• An electronic regulation module, with LCD screen.
• A rheostat.
• A module for the measurement of: solar irradiation (W/m2 ), solar panel temperature (°C), current up to 30V, ± 15A (two dc ammeters), voltage up to 40V and power up to 300W.
• A dc to ac converter module, with sinusoidal output at mains voltage. Average power: 300 W.
Average training hours: 8h.
Approx. packing dimensions: 0.62 x 1.21 x 0.82 m.
Net weight: 51 kg.
OPTION: DL SIMSUN
Composed of 4 halogen lamps, 300 W each, for lighting the solar tracking system.
Possibility to adjust the light intensity.
ALTERNATIVE: DL SOLAR-BT
Trainer with solar tracking panel instead of the standard solar panel.
Average training hours: 9h.

DL SOLAR-B

SOLAR POSITION TRACKING SYSTEM

For the study of the operation of a solar panel that follows the sun light direction thanks to a motor system.
Complete with connecting cables, experiment manual and software for control and data acquisition.
TRAINING OBJECTIVES
With the trainer, it is possible to monitor the most meaningful parameters of the sun tracker and to compare them with the expected optimal setting according to the actual sun position.
TECHNICAL SPECIFICATIONS
The trainer is composed of the following:
• A two-axis solar tracking system, 2 x 20W, 12V, to allow the tracking of the sun light direction.
• A supporting frame for the modules.
• A battery.
• A battery charge regulator, 12V, 30A.
• A circuit breaker.
OTHER FEATURES:
- Automatic or manual tracking.
- Temperature sensor.
- Humidity sensor
- Compass sensor.
- Protection against gust.
- RS485 Modbus RTU communication.
Average training hours: 3h approx.
Approx. packing dimensions: 0.50 x 1.05 x 0.90 m.
Net weight: 32 kg.

DL SUN-TRACKER

SOLAR ENERGY MODULAR TRAINER WITH CONNECTION TO MAINS

Didactic system for the study of the generation of electric energy from photovoltaic panels and its inlet in the mains network.
Complete with connecting cables, experiment manual and software for data acquisition and processing.
TRAINING OBJECTIVES
• Measuring the mains voltage
• Measuring the load current, voltage, power and energy
• Setting the solar panel to the most irradiated position
• Changing the inclination of the solar panel
• Changing the azimuth of the solar panel
• Covering the solar panel with different materials
• Obtaining the solar irradiation data
• Obtaining the solar panel voltage-irradiation curve • Calculating the inner resistance of the solar panel
• Obtaining the solar panel current-voltage curve
• Measuring the electricity delivered to the mains grid
• Measuring the electricity produced by the solar panel and delivered/taken from the mains grid
• Measuring the electricity produced by the solar panel, delivered/ taken from the mains grid, and the loading of lamps
TECHNICAL SPECIFICATIONS
• A photovoltaic inclinable module, 90W, 12V, complete with a cell for measuring the solar irradiation and with a temperature sensor.
• A supporting frame for the modules.
• A load module. It includes two mains voltage lamps, dichroic 35W and LED 3W, with independent switches.
• A power rheostat, 6 A, 80 W. A differential magneto-thermal switch module.
• A module for the measurement of: solar irradiation (W/m2 ), solar panel temperature (°C), solar panel current, load current, solar panel voltage and active power at mains voltage.
• A grid tie inverter, with output at mains voltage, 12 V, 300 W.
• An electric energy measurement module in kW/h.
• A network distributor.
Average training hours: 8 h.
Approx. packing dimensions: 0.62 x 1.21 x 0.82 m.
Net weight: 51 kg.
OPTION: DL SIMSUN
Composed of 4 halogen lamps, 300 W each, for lighting the solar tracking system.
Possibility to adjust the light intensity.
ALTERNATIVE: DL SOLAR-D1T
Trainer with solar tracking panel instead of the standard solar panel.
Average training hours: 9 h.

DL SOLAR-D1

PHOTOVOLTAIC AND THERMAL PANELS

The simulator allows the study, the performing of experiments and the troubleshooting for the following systems:
• Photovoltaic silicon single crystal cell, squared, side 135 mm
• Two photovoltaic cells with series connection
• Two photovoltaic cells with parallel connection
• Panel composed of 36 photovoltaic cells with series connection
• Thermal panel with liquid circulation
These systems are reproduced on the panel, through a colour representation which allows a complete analysis of the fluid circuit, of its components and of the electrical/electronic circuit for control and regulation.
TRAINING OBJECTIVES
It is possible to simulate the behaviour of components and systems, on the basis of the operating conditions which can be monitored directly on the panel or through Personal Computer by teacher and students.
The Personal Computer constantly keeps under control the simulation in progress and displays its behaviour through analog and digital signals and meters; in this way the student, through measurements and tests, can go on with the troubleshooting.
TECHNICAL DESCRIPTION
The experimentation on the photovoltaic systems (described here under) is organized as follows:
• Possibility to simulate several values of the solar radiation intensity (W/m2)
• Possibility to simulate several values of the photovoltaic cells temperature
• Possibility to change the electrical load of the above‐ mentioned photovoltaic systems
• Detection of the characteristic voltage‐current (V‐I), supplied by the photovoltaic systems, as a function of solar radiation intensity and cells temperature
• Detection of the characteristic voltage‐power (V‐P), sup‐ plied by the photovoltaic systems, as a function of solar radiation intensity and cells temperature
• Evaluation of the conversion efficiency (radiating energy‐electric power) of the photovoltaic systems
The experimentation on the thermal panel with liquid circulation is organized as follows:
• Possibility to simulate several values of the solar radiation intensity (W/m2)
• Possibility to simulate several values of the temperature of the thermal‐carrier liquid at the panel’s entrance
• Possibility to change the thermal‐carrier liquid capacity through the thermal panel
• Evaluation of the thermal‐carrier liquid temperature at the panel’s exit, as a function of the solar radiation intensity and of the entrance temperature
• Evaluation of the conversion efficiency (radiating energy‐ electric power) of the thermal panel
Average training hours: 10h (including 2h for fault finding).
Dimensions: 0.66 x 1.04 x 0.35 m.
Net weight: 16 kg.
The system is supplied with a Student Navigator software that allows students to perform their learning activities through a Personal Computer, without the need for any other documentation.
Moreover, the Student Navigator is provided with an interface to the Laboratory Management software.

DL TM11

Kit for the study of photovoltaic solar energy

Composed of:
• Sub‐module (2 off) with photovoltaic solar cell, for exercises with cells in both series and parallel configuration.
• Sub‐module with multifunction display, for the visualization of the measurements.
• Sub‐module with charge regulator, that can be connected to an external solar panel and to the battery.
• Sub‐module with breadboard, for the realization of circuits with components such as photodiodes.
• Sub‐module with battery controller to control the charge of the battery (it includes the external battery).
• Sub‐module for comparing the efficiency of different light sources; it includes a light sensor, incandescent lamps and LED.
• Sub‐module with voltage regulators.
• Sub‐module with current regulator and relay circuit, to switch between battery and power supply when the battery is out of charge.
• Solar panel, 5W
• Small fan (load)
• DL 3155BRS development module
• Power supply
Option:
• DL SL1 ‐ Spot light for the solar cells and the solar panel
Necessary instrumentation:multimeter
The kit is complete with theoretical and experiment manual.

DL 3155BRS–PSE

SOLAR PHOTOVOLTAIC ENERGY INSTALLATION KIT

Photovoltaic solar energy kit for the generation of electrical energy.
TRAINING OBJECTIVES
• To investigate how the solar irradiation influences the solar panel output voltage
• To calculate the inner resistance of the solar panels
• To obtain a daily irradiation curve
• To cover the solar panel with different materials
• To charge the battery using solar energy • To use both solar power and energy stored in the battery to power the DC load
• To test the complete system
TECHNICAL SPECIFICATIONS
• Two photovoltaic inclinable panels, 90W, 12V.
• A supporting frame for the panel. • An electronic current regulation module, with LCD screen, output 12 V, 30 A.
• An inverter, with output at mains voltage, 12 V, 30 A, 300 W.
• A battery control switch, 0-600 V, 32A with battery, 100 Ah.
• Two mains voltage lamps, dichroic 35W and LED 3W, with independent switches.
• Two 12V lamps, dichroic 20 W and LED 3W, with independent switches.
Cables, connectors and accessories.
• A frame for supporting the electrical components of the system: lamps, switches, protections, etc.
Average training hours: 8h.
The trainer is complete with installation manual.

DL SOLAR-KIT

Solar photovoltaic energy

The kit DL SOLAR‐L allows correlating school physics with practical usage of the photovoltaic cells.
The system has been conceived in such a way that most experiments can be conducted in normal room lighting.
An external current is not necessary for these experiments.
The lighting module (included) is required only for a few experiments, which can be operated with a students’ power supply.
COMPONENTS
• 3x Solar panel 0.5 V, 420 mA
• 1x Solar panel 0,5 V, 840 mA
• 1x Base unit
• 1x Lighting module
• 1x Diode module
• 1x Resistor module
• 1x Potentiometer module
• 1x Gear motor module
• 1x Colour filter
• 1x Solar cell cover set (4 pieces)
• 1x Plastic tray includes inserts
• 1x CD CD with manuals
• 1x Lid for tray
NECESSARY COMPONENTS
• 2x Digital multimeter
• 1x Power supply
• 2x Test lead ‐ black 25 cm
• 2x Test lead ‐ red 25 cm
• 1x Thermometer
EXPERIMENTS
• Series and parallel connection of solar cells
• Power dependence on the area of the solar cell
• Power dependence on the angle of incidence
• Power dependence on the level of illumination
• Determination of efficiency ratio of energy conversion
• Internal resistance of solar cells
• Dark characteristic curve of solar cell
• Inhibiting and conducting direction in illumination and darkness
• IV characteristic and fill factor of the solar cell
• IV characteristic of the solar cell in dependence on the level of illumination
• Dependence of the solar cell power on temperature
• Shading of solar cells in series connection
• Shading effect of solar cells in parallel connection
• The solar cell as a transmission measure
• Power dependence on the frequency of the incident light

DL SOLAR-L

Download Area

ProductsCodeCatalogueTender specsManuals SimpleVideo
LAMPS FOR PHOTOVOLTAIC TRAINERDL SIMSUN
PHOTOVOLTAIC SOLAR ENERGY TRAINERDL SOLAR-A
SOLAR ENERGY MODULAR TRAINERDL SOLAR-B
SOLAR POSITION TRACKING SYSTEMDL SUN-TRACKER
SOLAR PHOTOVOLTAIC ENERGY MODULAR TRAINER WITH CONNECTION TO MAINSDL SOLAR-D1
PHOTOVOLTAIC AND THERMAL PANELS SIMULATORDL TM11
SYSTEM FOR THE STUDY OF PHOTOVOLTAIC SOLAR ENERGYDL 3155BRS-PSE
SOLAR PHOTOVOLTAIC ENERGY INSTALLATION KITDL SOLAR-KIT
SOLAR PHOTOVOLTAIC ENERGYDL SOLAR-L
DL SOLAR-BDT
